Ref. No.:
1501-01101120
-
Media File
Machine Details:
-
Make:
-
Model:G350
-
Year of Build:01.2012
-
Availability:
-
Condition:
-
Location:
Technical Details:
-
Control:
-
Machine Hours:61.900 hrs.
-
Spindle Speed:16.000 rpm
-
Tool Holder:
-
Tool Capacity:99 x
-
X-Axis:600 mm
-
Y-Axis:855mm
-
Z-Axis:750 mm
Travels:
Description:
Description
Used Grob G350 universal machining center
- CNC control: SIEMENS SINUMERIK 840D sl MDynamics
- Operating hours: 61,900
Technical data:
- Travels:
- X/Y/Z axis: 600x770x805 mm
- Rotary table (B' axis)
- Z axis feed drive
- X/Y/Z speeds: 70/45/90m/min
- Positioning accuracy X/Y/Z: 0.006 mm
- Spindle:
- Motor spindle: 16,000 min-1, 160/223 Nm, 25/35 kW,
- Cooling system for the spindle
- Tool:
- Single disk magazine HSK-A 63 with 34 tool positions
- Additional tool magazine TM99 with 99 tools (HSK-A 63)
- Chip-to-chip time: 2.7s
- Tool length: 365 mm
- Pallet changing system
- Automatic 2-way pallet changer with setup station
- Pallet 400 x 400 mm with grid drilling pattern
- a zero-point clamping system on the rotary table (B-axis)
- Rotary distributor in the rotary table (B-axis)
- an additional hydraulic system for pallet clamping
- Table diameter: 570mm
- Table load: 340 kg
- Infrared measuring probe
- Renishaw
- Flushing gun & Blow gun
- Decentralized work area extraction, 600 m3/h
- Remote machine diagnosis
